Performance
|
Image Sensor | 1280×960 CMOS | |
| Illumination | Aiming |
Direct: White LED Diffuse: Ring of red LEDs 650nm laser diode |
|
| Symbologies | 2D 1D |
QR Code, Data Matrix EAN-8, EAN-13, UPC-E, UPC-A, Code128, Coupon, UCC/EAN128, CodaBar, I2Of5, Febraban, ITF14, ITF6, Matrix 25, Code39, Code93, ISSN, ISBN, Industrial 25, Standard 25, China Post 25, Plessey, Code 11, MSI Plessey, UCC/EAN Composite, GS1 Databar, Code 49, Code 16K, AIM 128, ISBT 128. |
|
| Resolution | ≥3mil | ||
| Typical Depth of Field | Code 39 Code 39 Data Matrix Data Matrix QR Code QR Code |
38mm-68mm (3.3mil) 18mm-90mm (5mil) 18mm-58mm (5mil) 0mm-90mm (10mil) 20mm-50mm (5mil) 0mm-90mm (10mil) |
|
| Scan Angle | Pitch: ±60°, Roll: 360°, Skew: ±55° | ||
| Min. Symbol Contrast | 20% | ||
| Motion Tolerance | Max. 2m/s (6.56ft/s) | ||
| Field of View | Horizontal 41°, Vertical 31° |
|
Physical
|
Dimensions (L×W×H) | 76(W)×107 (D)×179(H)mm | |
| Weight | 235g | ||
| Notification | Beep, LED, Vibration | ||
| Rated Power Consumption | 2250mW (typical) | ||
| Current@5VDC | Operating | 450mA (typical), 475mA (max.) | |
| Interfaces | RS-232, USB | ||
| Operating Voltage | 5VDC±5% |
|
Environmental
|
Operating Temperature | -20°C to 50°C (-4°F to 122°F) | |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) | ||
| Humidity | 5%~95% (non-condensing) | ||
| ESD | ±8 KV (direct discharge); ±16 KV (air discharge) | ||
| Drop | 1.8m/5.9ft | ||
| Sealing | IP42 |
|
Certifications
|
Certificates & Protection | FCC Part15 Class B, CE EMC Class B. RoHS |
