Scan Pattern Omnidirectional: 5 fields of 4 parallel lines; button activated single line (7180)
Scan Speed Omnidirectional: 1120 scan lines per second; single line: 56 scan lines per second (7180)
Print Contrast 35% minimum reflectance difference
Pitch, Skew 60°, 60°
Decode Capability Reads standard 1D and GS1 DataBar symbologies
Dimensions (LxWxH) 105 mm x 102 mm x 150 mm (4.1 in x 4.0 in x 5.9 in)
Weight 400 g (14.1 oz)
Operating Power 900 mW (180 mA @ 5 V)
Standby Power 850 mW (170mA @ 5 V)
Host System Interfaces USB, RS232, Keyboard Wedge, IBM 468xx (RS485)
